FINISAR Compatible FTLC1151RDPL Quick Spec
Part Number: FTLC1151RDPL
FTLC1151RDPL-EXT
FTLC1151RDPL-IND
Form Factor: QSFP28
TX Wavelength: 1310nm
Reach: 10km
Cable Type: SMF
Rate Category: 100GBase
Interface Type: LR4
DDM: Yes
Connector Type: Dual-LC
Optical Power Budget: 7.3 dB
TX Power Min/Max: -1.3 to 4.5 dBm
RX Power Min/Max: -8.6 to 4.5 dBm
FINISAR Compatible FTLC1151RDPL
Features:
• Hot pluggable QSFP28 MSA form factor
• Supports 103 Gbps and 112 Gbps
• Up to 10km reach for G.652 SMF
• Single +3.3V power supply
• Transmitter: cooled 4x25 Gbps LAN WDM EML TOSA (1295.56, 1300.05, 1304.58, 1309.14nm)
• Receiver: 4x25/28 Gbps PIN ROSA
• 4x28G Electrical Serial Interface (CEI-28GVSR)
• Maximum power consumption 4.5W
• RoHS-6 compliant (lead-free)
• Duplex LC receptacle
• I
2C interface with integrated Digital Diagnostic Monitoring
• Operating Case Temperature
o Standard 0 to +70 °C
o Extended -40 to +70 °C
o Industrial -40 to +85 °C
FINISAR Compatible FTLC1151RDPL Applications:
• 100GBASE-LR4 Ethernet links
• Infiniband QDR and DDR interconnects
• Client-side 100G telecom connections
• OTU4 4l1-9D1F
FINISAR Compatible FTLC1151RDPL Overview
The QSFP28-100GBaseLR4 is a 103/112 Gbps transceiver module designed for optical communication applications
compliant to 100GBASE-LR4 of the IEEE P802.3ba standard and OUT-4. The module converts 4 input channels of 25/28
Gbps electrical data to 4 channels of LAN WDM optical signals and then multiplexes them into a single channel for
103/112 Gbps optical transmission. Reversely on the receiver side, the module de-multiplexes a 103/112 Gbps optical
input into 4 channels of LAN WDM optical signals and then converts them to 4 output channels of electrical data. The
central wavelengths of the 4 LAN WDM channels are 1295.56, 1300.05, 1304.58 and 1309.14 nm as members of the LAN
WDM wavelength grid defined in IEEE 802.3ba. The high-performance cooled LAN WDM EA-DFB transmitters and high
sensitivity PIN receivers provide superior performance for 100G applications up to 10km links and compliant to optical
interface with IEEE802.3ba Clause 88 100GBASE-LR4 and OUT-4l1-9D1F requirements. The product is designed with
form factor, optical/electrical connection and digital diagnostic interface according to the QSFP+ Multi-Source Agreement
(MSA).
FAQ
1. Are your Optical Transceivers original?
Yes, all our optical transceivers are guaranteed 100% original!
2. What will you do if I found the product has any quality problem?
We back up every sale with our risk-free money-back guarantee! You can buy with confidence from a company in good faith that has been serving its clients for over 10 years!
3. What did your company do in terms of quality control?
We have professional testing equipment and QC team. Every unit will be fully tested with perfect performance before shipping.
4. What are the trade terms?
Lead Time: 1 day after confirm your payment (In stock, we need 1 day to fully test them)
Payment term: Western Union, T/T, Aliexpress Escow, Money Gram
Warranty: 1 Year
5. Do you have compatible ones?
Yes, we have our own brand—Toptrans, including SFP, XFP, SFP+, Bidi in all kinds of specifications.
